HEF4013BTR

HEF4013BTR, Dual D-type flip-flop, 14-SOIC, 15V, 40MHz, NXP Semiconductors

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~1.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~1.50

PartNumber:: HEF4013BTR

Brand:: NXP Semiconductors - nxp | Pack: DIP | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-30

From Other Seller

Part Number:HEF4013BTR
US $0.10 - 1.50
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The HEF4013BTR is a dual D-type flip-flop. The HEF4013BTR features independent set direct (SD), clear direct (CD), clock inputs (CP) and outputs (O, O). Data is accepted when CP is LOW and transferred to the output on the positive-going edge of the clock. The active HIGH asynchronous clear-direct (CD) and set-direct (SD) are independent and override the D or CP inputs. The outputs are buffered for best system performance. Schmitt-trigger action in the clock input makes the circuit highly tolerant to slower clock rise and fall times. The applications of the HEF4013BTR include Counters/dividers, Registers, Toggle flip-flops.

Parametrics

HEF4013BTR absolute maximum ratings: (1)VSS: 0 to 15 V; (2)Tamb = 25℃; (3)CL = 50 pF; (4)input transition times: ≤ 20 ns; (5)Maximum clock pulse frequency, fmax: 20 to 40MHz.

Features

HEF4013BTR features: (1)Set-up time , tsu: 15 ns; (2)Hold time D-CP, thold: 15 ns; (3)Minimum clock pulse witch; LOW, tWCPL: 20ns; (4)Minimum SD pulse width; HIGH, tWSDH: 20ns ; (5)Minimum CD pulse width; HIGH, tWCDH: 20ns; (6)Recovery time for SD, tRSD: 15ns; (7)Recovery time for CD, tRCD: 25ns; (8)Maximum clock pulse frequency, fmax: 40MHz.
