LP324M

LP324M, Micropower Quad Operational Amplifier, SOP, 32V or ± 16V, National Semiconductor

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.15~2.40 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.15~2.40

PartNumber:: LP324M

Brand:: National Semiconductor - NS | Pack: SOP | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-09

From Other Seller

Part Number:LP324M
US $0.15 - 2.40
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
IRF9540NPBF

US $0.50 - 3.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LP324M is a high gain internally compensated micropower operational amplifier. The amplifier is specially suited for operation in battery systems while maintaining good input specifications, and extremely low supply current drain. In addition, the LP324M has an input common mode range, and output source range which includes ground, making it ideal in single supply applications. The amplifier is ideal in applications which include portable instrumentation, battery backup equipment, and other circuits which require good DC performance and low supply current.

Parametrics

LP324M absolute maximum ratings: (1)Supply Voltage: 32V or ± 16V; (2)Differential Input Voltage: 32V; (3)Input Voltage (Note 2): -0.3V to 32V; (4)Output Short-Circuit to GND: Continuous; (5)V+ ≤ 15V and TA = 25℃, ESD Susceptibility: ±500V.

Features

LP324M features: (1)Low supply current: 125 μA (max); (2)Low offset voltage: 2 mV (max); (3)Low input bias current: 4 nA (max); (4)Input common mode to GND; (5)Interfaces to CMOS logic; (6)Wide supply range: 3V < V+ < 32V; (7)Small Outline Package available; (8)Pin-for-pin compatible with LM324.
