Product Summary

The LTC6904IMS8#TR is a serial port programmable oscillator. The LTC6904IMS8#TR is low power self contained digital frequency source providing a precision frequency from 1kHz to 68MHz, set through a serial port. The LTC6904IMS8#TR requires no external components other than a power supply bypass capacitor, and they operate over a single wide supply range of 2.7V to 5.5V. The LTC6904IMS8#TR is controlled by a convenient SPI compatible serial interface. The LTC6904IMS8#TR uses an industry standard I2C compatible interface. The applications of the LTC6904IMS8#TR are (1)critical μp power monitoring; (2)intelligent instruments; (3)battery-powered computers and controllers; (4)automotive systems.

Parametrics

LTC6904IMS8#TR absolute maximum ratings: (1)Total Supply Voltage (V+ to GND): 6V; (2)Maximum Voltage on any Pin: (GND – 0.3V)to (V+ + 0.3V); (3)Output Short Circuit Duration: Indefinite; (4)Operating Temperature Range: –40°C to 85°C; (5)Specified Temperature Range : –40°C to 85°C; (6)Storage Temperature Range : –65°C to 150°C; (7)Lead Temperature (Soldering, 10sec): 300°C.

Features

LTC6904IMS8#TR features: (1)precisiodigitally controlled oscillator; (2)power management; (3)direct digital frequency synthesis (DDS)replacement; (4)replacement for DAC and VCO; (5)switched capacitor filter clock.

Diagrams

LTC6904IMS8#TR pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
LTC6904IMS8#TR
LTC6904IMS8#TR


IC OSC SILICON 68MHZ 8MSOP

Data Sheet

0-5000: $1.65
LTC6904IMS8#TRPBF
LTC6904IMS8#TRPBF


IC OSC SILICON 68MHZ 8-MSOP

Data Sheet

0-2500: $1.65
