Product Summary
The M27C64A-20F1 is a 64Kbit EPROM offered in the two ranges UV (ultra violet erase) and OTP (one time programmable). The M27C64A-20F1 is ideally suited for microprocessor systems requiring large programs and is organized as 8,192 by 8 bits. A new pattern can then be written to the device by following the programming procedure. For applications where the content is programmed only on time and erasure is not required, the M27C64A-20F1 is offered in PLCC32 package.
Parametrics
M27C64A-20F1 absolute maximum ratings: (1)Ambient Operating Temperature, TA: -40 to 125℃; (2)Temperature Under Bias, TBIAS: -50 to 125℃; (3)Storage Temperature, TSTG: -65 to 150℃; (4)Input or Output Voltage, VIO: -2 to 7 V; (5)Supply Voltage, VCC: -2 to 7 V; (6)A9 Voltage, VA9: -2 to 13.5 V; (7)Program Supply Voltage, VPP: -2 to 14 V.
Features
M27C64A-20F1 features: (1)5V ± 10% supply voltage in read operation; (2)Fast access time: 150ns; (3)Low power “cmos” consumption: Active Current 30mA; Standby Current 100mA; (4)Programming voltage: 12.5V ± 0.25V; (5)High speed programming (less than 1 minute); (6)Electronic signature, manufacturer Code: 9Bh; Device Code: 08h.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 M27C64A-20F1 |
STMicroelectronics |
EPROM 64K (8Kx8) 200ns |
Data Sheet |
Negotiable |
|
||||
