Product Summary

The MIC29300-5.0WT is a high current, high accuracy, low-dropout voltage regulators. Using Micrel’s proprietary Super βeta PNP process with a PNP pass element, these regulators feature 350mV to 425mV (full load) typical dropout voltages and very low ground current. Designed for high current loads, the device also find applications in lower current, extremely low dropout-critical systems, where their tiny dropout voltage and ground current values are important attributes. The MIC29300-5.0WT is fully protected against overcurrent faults, reversed input polarity, reversed lead insertion, overtemperature operation, and positive and negative transient voltage spikes. The applications of the MIC29300-5.0WT include Battery powered equipment, High-efficiency "green" computer systems, Automotive electronics, High-efficiency linear lower supplies, High-efficiency lost-regulator for switching supply.

Parametrics

MIC29300-5.0WT absolute maximum ratings: (1)Input Supply Voltage (VIN): -20V to +60V; (2)Enable Input Voltage (VEN): -0.3V to VIN; (3)Lead Temperature (soldering, 5sec.): 260℃; (4)Power Dissipation: Internally Limited; (5)Storage Temperature Range: -65℃ to +150℃.

Features

MIC29300-5.0WT features: (1)High current capability: 3A; (2)Low-dropout voltage; (3)Low ground current; (4)Accurate 1% guaranteed tolerance; (5)Extremely fast transient response; (6)Reverse-battery and "load Dump" protection; (7)Zero-current shutdown mode (5-pin versions); (8)Error flag signals output out-of-regulation (5-pin versions); (9)Also characterized for smaller loads with industryleading; (10)performance specifications; (11)Fixed voltage and adjustable versions.
