Product Summary

The AD22282-A-R2 is a low power, complete single-axis accelerometer with signal conditioned voltage outputs that are all on a single monolithic IC. This product measures acceleration with a full-scale range of ±120 g or ±250 g (minimum). It can also measure both dynamic acceleration (vibration) and static acceleration (gravity). The AD22282-A-R2 is a fourth-generation surface micromachined iMEMS accelerometer from ADI with enhanced performance and lower cost. The applications of the AD22282-A-R2 include Vibration monitoring and control, Vehicle collision sensing, Shock detection.

Parametrics

AD22282-A-R2 absolute maximum ratings: (1)Acceleration (Any Axis, Unpowered): 4,000 g; (2)Acceleration (Any Axis, Powered): 4,000 g; (3)VS: -0.3 V to +7.0 V; (4)All Other Pins: (COM -0.3 V) to (VS +0.3 V); (5)Output Short-Circuit Duration (Any Pin to Common): Indefinite; (6)Operating Temperature Range: -65℃ to +150℃; (7)Storage Temperature: -65℃ to +150℃.

Features

AD22282-A-R2 features: (1)Complete acceleration measurement system on a single monolithic IC; (2)Available in ±120 g or ±250 g output full-scale ranges; (3)Full differential sensor and circuitry for high resistance to EMI/RFI; (4)Environmentally robust packaging; (5)Complete mechanical and electrical self-test on digital command; (6)Output ratiometric to supply; (7)Sensitive axes in the plane of the chip; (8)High linearity (0.2% of full scale); (9)Frequency response down to dc; (10)Low noise; (11)Low power consumption (1.5 mA); (12)Tight sensitivity tolerance and 0 g offset capability; (13)Largest available prefilter clipping headroom; (14)400 Hz, 2-pole Bessel filter; (15)Single-supply operation; (16)Compatible with Sn/Pb and Pb-free solder processes.
