ADC08131CIWM

ADC08131CIWM, 8-bit successive approximation A/D converter, SOP, 6.5V, 20mA, National Semiconductor

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.15~2.40 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.15~2.40

PartNumber:: ADC08131CIWM

Brand:: National Semiconductor - NS | Pack: SOP | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-09

From Other Seller

Part Number:ADC08131CIWM
US $0.15 - 2.40
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The ADC08131CIWM is an 8-bit successive approximation A/D converter with serial I/O and configurable input multiplexers with up to 8 channels. The serial I/O is configured to comply with the NSC MICROWIRE serial data exchange standard for easy interface to the COPS family of controllers, and can easily interface with standard shift registers or microprocessors. The ADC08131CIWM provides a 2.5V band-gap derived reference with guaranteed performance over temperature. A track/hold function allows the analog voltage at the positive input to vary during the actual A/D conversion. The applications of the ADC08131CIWM include Digitizing automotive sensors, Process control/monitoring, Remote sensing in noisy environments, Embedded diagnostics.

Parametrics

ADC08131CIWM absolute maximum ratings: (1)Supply Voltage (VCC): 6.5V; (2)Voltage at Inputs and Outputs: -0.3V to VCC + 0.3V; (3)Input Current at Any Pin (Note 4): ±5 mA; (4)Package Input Current (Note 4): ±20 mA; (5)Power Dissipation at TA = 25℃(Note 5): 800 mW; (6)ESD Susceptibility (Note 6): 1500V.

Features

ADC08131CIWM features: (1)Serial digital data link requires few I/O pins; (2)Analog input track/hold function; (3)4- or 8-channel input multiplexer options with address logic; (4)On-chip 2.5V band-gap reference (±2% over temperature guaranteed); (5)No zero or full scale adjustment required; (6)TTL/CMOS input/output compatible; (7)0V to 5V analog input range with single 5V power supply.
