Product Summary

The ADM241LARZ is a driver/receiver. The ADM241LARZ is intended for all EIA-232-E and V.28 communications interfaces, especially in applications where ±12 V is not available. The ADM241LARZ features a low power shutdown mode that reduces power dissipation to less than 5 mW, making them ideally suited for battery powered equipment. Two receivers remain enabled during shutdown on the ADM223. The ADM233L and ADM235L do not require any external components and are particularly useful in applications where printed circuit board space is critical.

Parametrics

ADM241LARZ absolute maximum ratings: (1)VCC: －0.3 V to +6 V; (2)V+: (VCC － 0.3 V)to +14 V; (3)V－: +0.3 V to －14 V Input Voltages; (4)Range: －65℃ to + 150℃; (5)Lead Temperature, Soldering: +300℃; (6)Vapour Phase (60 sec): +215℃; (7)Infrared (15 sec): +220℃; (8)ESD Rating: >2000 V.

Features

ADM241LARZ features: (1)Single 5 V Power Supply; (2)Meets All EIA-232-E and V.28 Specifications; (3)120 kB/s Data Rate; (4)On-Board DC-DC Converters; (5)69 V Output Swing with +5 V Supply; (6)Small 1 mF Capacitors; (7)Low Power Shutdown £1 mA; (8)Receivers Active in Shutdown (ADM223); (9)ESD > 2 kV; (10)630 V Receiver Input Levels; (11)Latch-Up FREE; (12)Plug-In Upgrade for MAX223/230-241; (13)Plug-In Upgrade for AD230–AD241.

Diagrams

ADM241LARZ pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
ADM241LARZ
ADM241LARZ

IC TXRX RS-232 4:5 5V LP 28-SOIC
Data Sheet
0-189: $1.46
ADM241LARZ-REEL
ADM241LARZ-REEL

IC TXRX RS-232 4:5 5V LP 28SSOP
Data Sheet
0-1000: $1.00
