AT24C512N-10SU-2.7

AT24C512N-10SU-2.7, Two-wire Serial EEPROM, SOIC-8, 6.25V, 5mA, ATMEL Corporation

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.30~0.50

PartNumber:: AT24C512N-10SU-2.7

Brand:: ATMEL Corporation - ATMEL | Pack: SOIC | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-29

From Other Seller

Part Number:AT24C512N-10SU-2.7
US $0.30 - 0.50
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
IRF3205

US $0.80 - 2.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT24C512N-10SU-2.7 is a Two-wire Serial EEPROM. The AT24C512N-10SU-2.7 provides 524,288 bits of serial electrically erasable and programmable read only memory (EEPROM) organized as 65,536 words of 8 bits each. The device’s cascadable feature allows up to four devices to share a common two-wire bus. The device is optimized for use in many industrial and commercial applications where lowpower and low-voltage operation are essential. The AT24C512N-10SU-2.7 is available in spacesaving 8-pin PDIP, 8-lead EIAJ SOIC, 8-lead JEDEC SOIC, 8-lead TSSOP, 8-lead Leadless Array (LAP), and 8-lead SAP packages. In addition, the entire family is available in 2.7V (2.7V to 5.5V) and 1.8V (1.8V to 3.6V) versions.

Parametrics

AT24C512N-10SU-2.7 absolute maximum ratings: (1)Operating Temperature: -55℃ to +125℃; (2)Operating Temperature: -55℃ to +125℃; (3)Voltage on Any Pin with Respect to Ground: -1.0V to +7.0V; (4)Maximum Operating Voltage: 6.25V; (5)DC Output Current: 5.0 mA.

Features

AT24C512N-10SU-2.7 features: (1)Low-voltage and Standard-voltage Operation, 2.7 (VCC = 2.7V to 5.5V); 1.8 (VCC = 1.8V to 3.6V); (2)Internally Organized 65,536 x 8; (3)Two-wire Serial Interface; (4)Schmitt Triggers, Filtered Inputs for Noise Suppression; (5)Bidirectional Data Transfer Protocol; (6)1 MHz (5V), 400 kHz (2.7V) and 100 kHz (1.8V) Compatibility; (7)Write Protect Pin for Hardware and Software Data Protection; (8)128-byte Page Write Mode (Partial Page Writes Allowed); (9)Self-timed Write Cycle (5 ms Max); (10)High Reliability, Endurance: 100,000 Write Cycles; Data Retention: 40 Years; (11)Automotive Devices Available; (12)8-lead PDIP, 8-lead EIAJ SOIC, 8-lead JEDEC SOIC, 8-lead TSSOP, 8-lead LAP, 8-lead SAP and 8-ball dBGA2 Packages; (13)Die Sales: Wafer Form, Waffle Pack and Bumped Die.
