Product Summary

The BC807-25 is a PNP general purpose transistor. The BC807-25 in a SOT23 plastic package. NPN complements: BC817. The applications of the BC807-25 include General purpose switching and amplification.

Parametrics

BC807-25 absolute maximum ratings: (1)collector-base voltage, open emitter, VCBO: -50 V; (2)collector-emitter voltage, open base; IC = -10 mA, VCEO: -45 V; (3)emitter-base voltage open collector, VEBO: -5 V; (4)collector current (DC), IC: -500 mA; (5)peak collector current, ICM: -1 A; (6)peak base current, IBM: -200 mA; (7)total power dissipation Tamb ≤25℃, Ptot: 250 mW; (8)storage temperature, Tstg: -65 +150℃; (9)junction temperature, Tj: 150℃; (10)operating ambient temperature, Tamb: -65 +150℃.

Features

BC807-25 features: (1)High current (max. 500 mA); (2)Low voltage (max. 45 V).

Diagrams

BC807-25 circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
BC807-25 /T3
BC807-25 /T3

NXP Semiconductors

Transistors Bipolar (BJT) TRANS GP TAPE-13

Data Sheet

Negotiable
BC807-25,215
BC807-25,215

NXP Semiconductors

Transistors Bipolar (BJT) PNP45V 500mA

Data Sheet

0-1: $0.03
1-25: $0.01
25-100: $0.01
100-250: $0.01
BC807-25,235
BC807-25,235

NXP Semiconductors

Transistors Bipolar (BJT) TRANS GP TAPE-13

Data Sheet

0-1: $0.03
1-25: $0.01
25-100: $0.01
100-250: $0.01
BC807-25-7
BC807-25-7

Diodes Inc.

Transistors Bipolar (BJT) PNP BIPOLAR

Data Sheet

Negotiable
BC807-25-7-F
BC807-25-7-F

Diodes Inc.

Transistors Bipolar (BJT) PNP BIPOLAR

Data Sheet

0-1: $0.31
1-10: $0.22
10-100: $0.13
100-250: $0.09
BC807-25LT1G
BC807-25LT1G

ON Semiconductor

Transistors Bipolar (BJT) 500mA 50V PNP

Data Sheet

0-1: $0.09
1-25: $0.07
25-100: $0.03
100-500: $0.02
BC807-25LT3G
BC807-25LT3G

ON Semiconductor

Transistors Bipolar (BJT) 500mA 50V PNP

Data Sheet

0-1: $0.10
1-25: $0.08
25-100: $0.06
100-500: $0.03
BC807-25T116
BC807-25T116


TRANSISTOR PNP 45V 0.05A SMT3

Data Sheet

0-3000: $0.05
