MIC2548-1BM

integrated high-side power switch, 2kV, 50mA, 120mΩ, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.15~2.40 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.15~2.40

PartNumber:: MIC2548-1BM

Brand:: Micrel Semiconductor - Micrel | Pack: SOP | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-09

From Other Seller

Part Number:MIC2548-1BM
US $0.15 - 2.40
CM300DY-12NF

US $63.00 - 80.00 / Piece
(0) Remove
STK795-810

US $12.00 - 16.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MIC2548-1BM is an integrated high-side power switch optimized for low loss dc power switching and other power management applications, including Advanced Configuration and Power Interface (ACPI). The MIC2548-1BM is a cost effective, highly integrated solution that requires few external components to satisfy USB and ACPI requirements. The MIC2548-1BM applications are: (1)USB power distribution; (2)PCI Bus Power Switching; (3)Notebook PC; (4)ACPI power distribution; (5)PC card hot swap applications; (6)Inrush current-limiting.

Parametrics

MIC2548-1BM absolute maximum ratings: (1)Supply Voltage (VIN): +6.0V; (2)Output Voltage (VOUT): +6.0V; (3)Output Current (IOUT): Internally Limited; (4)Enable Input (VEN): －0.3V to VIN+0.3V; (5)Fault Flag Voltage (VFLG): +6.0V; (6)Fault Flag Current (IFLG): 50mA; (7)Storage Temperature (TS): －65℃ to +150℃; (8)Junction Temperature (TJ): Internally Limited; (9)Lead Temperature (soldering 5 sec.): 260℃; (10)ESD Rating, Note 3 : 2kV.

Features

MIC2548-1BM features: (1)2.7V to 5.5V input; (2)Adjustable current-limit up to 1.5A; (3)Reverse current flow blocking (no body diode ); (4)120mΩ maximum on-resistance; (5)Open-drain fault flag; (6)Thermal shutdown; (7)Thermal shutdown output latch (MIC2548); (8)2ms (slow)turn-on and fast turnoff; (9)Available with active-high or active-low enable.
