Product Summary

The PIC16LF1827-I/MV is a flash microcontroller with nanoWatt XLP technology. The PIC16LF1827-I/MV is available in 18/20/28-pin packages.

Parametrics

PIC16LF1827-I/MV absolute maximum ratings: (1)Ambient temperature under bias: -40℃ to +125℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on VDD with respect to VSS: -0.3V to +4.0V; (4)Voltage on MCLR with respect to Vss: -0.3V to +9.0V; (5)Voltage on all other pins with respect to VSS: -0.3V to (VDD + 0.3V); (6)Total power dissipation: 800 mW; (7)Maximum current out of VSS pin: 95 mA; (8)Maximum current into VDD pin: 70 mA; (9)Clamp current, IK (VPIN < 0 or VPIN > VDD): 20 mA; (10)Maximum output current sunk by any I/O pin: 25 mA; (11)Maximum output current sourced by any I/O pin: 25 mA; (12)Maximum current sunk by all ports(2), -40℃ ≤ TA ≤ +85℃ for industrial: 200 mA; (13)Maximum current sunk by all ports(2), -40℃ ≤ TA ≤ +125℃ for extended: 90 mA; (14)Maximum current sourced by all ports(2), 40℃ ≤ TA ≤ +85℃ for industrial: 140 mA; (15)Maximum current sourced by all ports(2), -40℃ ≤ TA ≤ +125℃ for extended: 65 mA.

Features

PIC16LF1827-I/MV features: (1)C Compiler Optimized Architecture; (2)256 bytes Data EEPROM; (3)Up to 4 Kbytes Linear Program Memory Addressing; (4)Up to 384 bytes Linear Data Memory Addressing; (5)Interrupt Capability with Automatic Context Saving; (6)16-Level Deep Hardware Stack with Optional Overflow/Underflow Reset; (7)Direct, Indirect and Relative Addressing modes: Two full 16-bit File Select Registers (FSRs); FSRs can read program and data memory.
