SI4408DY-T1-E3

n-channel 20-v (d-s) mosfet, 20 V, 14 A, 1.6W, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.15~2.40 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.15~2.40

PartNumber:: SI4408DY-T1-E3

Brand:: Vishay Siliconix - Vishay | Pack: SOP | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-09

From Other Seller

Part Number:SI4408DY-T1-E3
US $0.15 - 2.40
SIL9030CTU

US $2.50 - 5.10 / Piece
(0) Remove
TOP259EN

US $1.10 - 3.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SI4408DY-T1-E3 is a n-channel 20-v (d-s) mosfet. The SI4408DY-T1-E3 application is Self-Driven Synchronous Rectification.

Parametrics

SI4408DY-T1-E3 absolute maximum ratings: (1)Drain Source Voltage VDS: 20 V; (2)Gate Source Voltage VGS: ± 20 V; (3)Continuous Drain Current (TJ = 150 °C)a TA = 25 °C ID: 21, 14 A; (4)Pulsed Drain Current (10 us Pulse Width)IDM: 60 A; (5)Continuous Source Current (Diode Conduction)a IS: 2.9, 1.3A; (6)Maximum Power Dissipationa TA = 25 °C PD: 3.5, 1.6W.

Features

SI4408DY-T1-E3 features: (1)Halogen-free According to IEC 61249-2-21 Available; (2)TrenchFET Power MOSFET; (3)PWM Optimized for Fast Switching; (4)Low Switching Losses; (5)Low Gate Drive Losses; (6)100 % Rg Tested.
