Product Summary
The UPD444012AGY-B55X-MJH-A is a high speed, low power, 4,194,304 bits (262,144 words by 16 bits) CMOS static RAM. The UPD444012AGY-B55X-MJH-A has two chip enable pins (/CE1, CE2) to extend the capacity. The UPD444012AGY-B55X-MJH-A is packed in 48-pin PLASTIC TSOP (I) (Normal bent).
Parametrics
UPD444012AGY-B55X-MJH-A absolute maximum ratings: (1)Supply voltage, VCC: -0.5 Note to +4.0 V; (2)Input / Output voltage, VT: -0.5 Note to VCC + 0.4 (4.0 V MAX.) V; (3)Operating ambient temperature, TA: -25 to +85℃; (4)Storage temperature, Tstg: -55 to +125℃.
Features
UPD444012AGY-B55X-MJH-A features: (1)262,144 words by 16 bits organization; (2)Fast access time: 50, 55, 70, 85, 100, 120 ns (MAX.); (3)Byte data control: /LB (I/O1 - I/O8), /UB (I/O9 - I/O16); (4)Low voltage operation (B version: VCC = 2.7 to 3.6 V, C version: VCC = 2.2 to 3.6 V); (5)Low VCC data retention: 1.0 V (MIN.); (6)Operating ambient temperature: TA = -25 to +85℃; (7)Output Enable input for easy application; (8)Two Chip Enable inputs: /CE1, CE2.
Diagrams
 |
