XC4005-5PC84C

XC4005-5PC84C, Field Programmable Gate Array, 84PLCC, 5.5V, 500mA, Xilinx, Inc

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.20~1.60 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.20~1.60

PartNumber:: XC4005-5PC84C

Brand:: Xilinx, Inc - Xilinx | Pack: DIP | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-06

From Other Seller

Part Number:XC4005-5PC84C
US $0.20 - 1.60
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
HT46R47

US $0.35 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The XC4005-5PC84Cis a Field Programmable Gate Array.

Parametrics

XC4005-5PC84C absolute maximum ratings: (1)Supply voltage relative to Ground, VCC: -0.5 to 4.0 V; (2)Input voltage relative to Ground, VIN: -0.5 to 5.5 V; (3)Voltage applied to 3-state output, VTS: -0.5 to 5.5 V; (4)Longest Supply Voltage Rise Time from 1 V to 3V, VCCt: 50 ms; (5)Storage temperature (ambient), TSTG: -65 to +150℃; (6)Maximum soldering temperature (10 s @ 1/16 in. = 1.5 mm), TSOL: +260℃; (7)Junction Temperature, Ceramic packages, TJ: +150℃; Plastic packages, TJ: +125℃.

Features

XC4005-5PC84C features: (1)High-level output voltage @ IOH = -4.0 mA, VCC min (LVTTL), VOH: 2.4 V; (2)High-level output voltage @ IOH = -500 mA, (LVCMOS), VOH: 90% VCC V; (3)Low-level output voltage @ IOL = 12.0 mA, VCC min (LVTTL), VOL: 0.4 V; (4)Low-level output voltage @ IOL = 1500 mA, (LVCMOS), VOL: 10% VCC V; (5)Data Retention Supply Voltage (below which configuration data may be lost), VDR: 2.5 V; (6)Quiescent FPGA supply current, ICCO: 5 mA; (7)Input or output leakage current, IL: -10 to +10 mA; (8)Input capacitance (sample tested) BGA, SBGA, PQ, HQ, MQ packages, CIN: 10 pF; PGA packages, CIN: 16 pF; (9)Pad pull-up (when selected) @ Vin = 0 V (sample tested), IRPU: 0.02 to 0.25 mA; (10)Pad pull-down (when selected) @ Vin = 3.6 V (sample tested), IRPD: 0.02 to 0.15 mA; (11)Horizontal Longline pull-up (when selected) @ logic Low, IRLL: 0.3 to 2.0 mA.
