AD7887AR

AD7887AR, low power 12-bit ADC, SOP8, 7V, 450mW, Analog Devices

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.15~2.40 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.15~2.40

PartNumber:: AD7887AR

Brand:: Analog Devices - ADI | Pack: SOP | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-09

From Other Seller

Part Number:AD7887AR
US $0.15 - 2.40
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AD7887AR is a high speed, low power, 12-bit ADC that operates from a single +2.7 V to +5.25 V power supply. The AD7887AR is capable of 125 kSPS throughput rate. The input track-andhold acquires a signal in 500 ns and features a single-ended sampling scheme. The applications of the AD7887AR are Battery-Powered Systems (Personal Digital Assistants, Medical Instruments, Mobile Communications), Instrumentation and Control Systems, High Speed Modems.

Parametrics

AD7887AR absolute maximum ratings: (1)VDD to AGND: -0.3 V to +7 V; (2)Analog Input Voltage to AGND: -0.3 V to VDD +0.3 V; (3)Digital Input Voltage to AGND: -0.3 V to VDD +0.3 V; (4)Digital Output Voltage to AGND: -0.3 V to VDD +0.3 V; (5)REFIN/REFOUT to AGND: -0.3 V to VDD +0.3 V; (6)Input Current to Any Pin Except Supplies: ±10 mA; (7)Operating Temperature Range: Commercial: A, B Versions: -40℃ to +125℃; (8)Storage Temperature Range: –65℃ to +150℃; (9)Junction Temperature: +150℃; (10)SOIC, mSOIC Package, Power Dissipation: 450 mW.

Features

AD7887AR features: (1)Specified for VDD of +2.7 V to +5.25 V; (2)Flexible Power/Throughput Rate Management; (3)Shutdown Mode: 1 uA Max; (4)One/Two Single-Ended Inputs; (5)Serial Interface: SPI/QSPI/MICROWIRE/DSP Compatible; (6)8-Lead Narrow SOIC and uSOIC Packages.
