BAV70, High-speed double diode, SOT23, 85V, 125mA, NXP Semiconductors

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.01~0.01 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.01~0.01

PartNumber:: BAV70

Brand:: NXP Semiconductors - nxp | Pack: SOT | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-19

From Other Seller

Part Number:BAV70
US $0.01 - 0.01
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The BAV70 is a high-speed double diode. The BAV70 consists of two high-speed switching diodes with common cathodes, fabricated in planar technology, and encapsulated in the small SOT23 plastic SMD package. The applications of the BAV70 include High-speed switching in thick and thin-film circuits.

Parametrics

BAV70 absolute maximum ratings: (1)repetitive peak reverse voltage, VRRM: 85 V; (2)continuous reverse voltage, VR: 75 V; (3)continuous forward current, single diode loaded, IF: 215mA; double diode loaded, IF: 125 mA; (4)repetitive peak forward current, IFRM: 450 mA; (5)non-repetitive peak forward current square wave; Tj = 25℃ prior to surge, t = 1μs, IFSM: 4 A; t = 1 ms, IFSM: 1 A; t = 1 s, IFSM: 0.5 A; (6)total power dissipation Tamb = 25℃, Ptot: 250 mW; (7)storage temperature, Tstg: -65 +150℃; (8)junction temperature, Tj: 150℃.

Features

BAV70 features: (1)Small plastic SMD package; (2)High switching speed: max. 4 ns; (3)Continuous reverse voltage: max. 70 V; (4)Repetitive peak reverse voltage: max. 75 V; (5)Repetitive peak forward current: max. 450 mA.
