LH28F160S5HT-L70

LH28F160S5HT-L70, 16M Flash Memory, 56-TFSOP, 7V, 100mA, Sharp Electrionic Components

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.20~1.60 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.20~1.60

PartNumber:: LH28F160S5HT-L70

Brand:: Sharp Electrionic Components - Sharp | Pack: DIP | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-07

From Other Seller

Part Number:LH28F160S5HT-L70
US $0.20 - 1.60
CM2030-A0TR

US $0.92 - 2.50 / Piece
(0) Remove
HEF4093BT

US $0.15 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LH28F160S5HT-L70 is a 16M (2MB × 8/1MB × 16) flash memory. The LH28F160S5HT-L70 flash memory with smart 5 technology is a high density, low cast, nonvolatile, read/wriite storage solution for a wide range of applications. Its symmetrically blocked architechture, flexible voltage and extended cycling provide for highly flexible component suitable for resident flash arrays, SIMMs and memory cards. The LH28F160S5HT-L70 enhanced suspend capabilities provide for an ideal solution for code + data storage applications.

Parametrics

LH28F160S5HT-L70 absolute maximum ratings: (1)Operating temperature, block lock bit configuration: -40 to 85℃; (2)Temperature under bias: -40 to 85℃; (3)Storage temperature: -65 to +125℃; (4)Voltage on any pin: -0.5 to Vcc +0.5V; (5)Vcc supply voltage: -0.2 to 7.0V; (6)Output short circuit current: 100mA.

Features

LH28F160S5HT-L70 features: (1)Smart 5 technology; (2)Common flash interface; (3)Scalable command set; (4)High speed write performance; (5)High speed read performance; (6)Operating temperature; (7)Enhanced automated suspend options; (8)High density symmetrically blocked architecture; (9)SRAM compatible write interface; (10)User configurable x8 or x16 operation.
