Product Summary
The LT1004IS8-2.5#TR is a Micropower Voltage Reference. The LT1004IS8-2.5#TR is a 2-terminal bandgap reference diode designed to provide high accuracy and excellent temperature characteristics at very low operating currents. Optimization of the key parameters in the design, processing and testing of the LT1004IS8-2.5#TR results in accuracy specifications previously attainable only with selected units. Below is a distribution plot of reference voltage for a typical lot of LT1004-1.2 Virtually all of the units fall well within the prescribed limits of ±4mV. The applications of the LT1004IS8-2.5#TR include Portable Meter References, Portable Test Instruments, Battery-Operated Systems, Current Loop Instrumentation.
Parametrics
LT1004IS8-2.5#TR absolute maximum ratings: (1)Reverse Breakdown Current: 30mA; (2)Forward Current: 10mA; (3)Operating Temperature Range: 0℃ to 70℃; (4)Storage Temperature Range: -65℃ to 150℃; (5)Lead Temperature (Soldering, 10 sec.): 300℃.
Features
LT1004IS8-2.5#TR features: (1)Guaranteed ±4mV Initial Accuracy LT1004-1.2; (2)Guaranteed ±20mV Accuracy LT1004-2.5; (3)Guaranteed 10mA Operating Current; (4)Guaranteed Temperature Performance; (5)Operates up to 20mA; (6)Very Low Dynamic Impedance.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LT1004IS8-2.5#TR |
|
IC VREF SHUNT 2.5V 8-SOIC |
Data Sheet |
|
|
||||||
|
LT1004IS8-2.5#TRPBF |
|
IC VREF SHUNT 2.5V 8-SOIC |
Data Sheet |
|
|
||||||
