Product Summary
The LT1317BCMS8#TR is a micropower, 600kHz PWM DC/DC converter. Peak switch current during Burst Mode operation is kept below 250mA for most operating conditions which results in low output ripple voltage, even at high input voltages. Its applications include Cellular Telephones, Cordless Telephones, Pagers, GPS Receivers, Battery Backup, Portable Electronic Equipment, Glucose Meters, Diagnostic Medical Instrumentation.
Parametrics
LT1317BCMS8#TR absolute maximum ratings: (1)LBO voltage: 12V; (2)SW voltage: -0.4 to 30V; (3)FB voltage: VIN +0.3V; (4)VC voltage: 2V; (5)SHDN voltage: 6V; (6)junction temperature: 125℃; (7)operating temperature range: 0 to 70℃; (8)storage temperature range: -65 to 150℃; (9)lead temperature: 300℃.
Features
LT1317BCMS8#TR features: (1)100µA Quiescent Current; (2)Operates with VIN as Low as 1.5V; (3)600kHz Fixed Frequency Operation; (4)Starts into Full Load; (5)Low-Battery Detector Active in Shutdown; (6)Low VCESAT; (7)Switch: 300mV at 500mA.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LT1317BCMS8#TR |
|
IC REG BOOST ADJ 0.5A 8MSOP |
Data Sheet |
|
|
||||||
|
LT1317BCMS8#TRPBF |
|
IC REG BOOST ADJ 0.5A 8MSOP |
Data Sheet |
|
|
||||||
