TLC542CDWRG4

CMOS converter, SOP-20, ±30 mA, 6.5 V, 12-Channel Analog Multiplexer, Built-In Self-Test Mode

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~0.80 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.50~0.80

PartNumber:: TLC542CDWRG4

Brand:: Texas Instruments - TI | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-10-08

From Other Seller

Part Number:TLC542CDWRG4
US $0.50 - 0.80
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TLC542CDWRG4 is a CMOS converter built around an 8-bit switched-capacitor successive-approximation analog-to-digital converter. The TLC542CDWRG4 is designed for serial interface to a microprocessor or peripheral via a 3-state output with three inputs [including I/O CLOCK, CS (chip select), and ADDRESS INPUT]. The TLC542CDWRG4 allows high-speed data transfers and sample rates of up to 40,000 samples per second. In addition to the high-speed converter and versatile control logic, an on-chip 12-channel analog multiplexer can sample any one of 11 inputs or an internal self-test voltage, and the sample and hold is started under microprocessor control. At the end of conversion, the end-of-conversion (EOC) output pin goes high to indicate that conversion is complete.

Parametrics

TLC542CDWRG4 absolute maximum ratings: (1)Supply voltage, VCC: 6.5 V; (2)Input voltage range (any input): –0.3 V to VCC + 0.3 V; (3)Output voltage range, VO: –0.3 V to VCC+ 0.3 V; (4)Peak input current range (any input), Ip-p): ±20 mA; (5)Peak total input current (all inputs), IP: ±30 mA; (6)Operating free-air temperature range: 0 to 70℃; (7)Storage temperature range, Tstg: –65 to 150℃; (8)Case temperature for 10 seconds, TC: FN package: 260℃; (9)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: DW or N package: 260℃.

Features

TLC542CDWRG4 features: (1)8-Bit Resolution A/D Converter; (2)Microprocessor Peripheral or Stand-Alone Operation; (3)On-Chip ; (4)Built-In Self-Test Mode; (5)Software-Controllable Sample and Hold; (6)Total Unadjusted Error ... ±0.5 LSB Max; (7)Direct Replacement for Motorola MC145041; (8)Onboard System Clock; (9)End-of-Conversion (EOC) Output; (10)Pinout and Control Signals Compatible With the TLC1542/3 10-Bit A/D Converters; (11)CMOS Technology.
