The LT1796CS8#TR transceiver provides built-in fault tolerance to survive in industrial and automotive environment. Bus interface pins of the LT1796CS8#TR can withstand voltage faults up to ±60V with respect to ground with no damage to the device. Faults may occur while the LT1796CS8#TR is active, shut down or powered off. Applications of the LT1796CS8#TR include: Industrial Control Data Networks, Automotive Systems, HVAC Controls.
Parametrics
LT1796CS8#TR absolute maximum ratings: (1) Supply Voltage (Vcc ) : 44V; (2) Rs Slope Control Input Voltage: -0.3V to 44V; (3) Vref Reference Output Pin: -0.3V to 7 V; (4) Driver Input Voltage: -0.3V to 7V; (5) CANH, CANL Data Line Pins: -80V to 80V; (6) Receiver Output Voltages: -0.3V to 7V; (7) Operating Temperature Range: 0°C to 70°C; (8) Storage Temperature Range: -65°C to 150°C; (9) Lead Temperature (Soldering, 10 sec) : 300°C.
Features
LT1796CS8#TR features: ( 1) Protected from Overvoltage Line Faults to ±60V; (2) ESD Protection to IEC-1000-4-2 Level 4: ±15kV Air Gap Test, ±8kV Contact Mode Test; (3) ISO 11898 Compatible; (4) High Input Impedance Supports Up to 256 Nodes; (5) Controlled Slew Rates for EMI Emissions Control; (6) High Impedance Outputs When Off or Powered Down; (7) Short-Circuit Protection On All Outputs; (8) Thermal Shutdown Protection; (9) Pin Compatible with Philips PCA82C251.
