Product Summary

The LTC1258CMS8-5#TR is a micropower bandgap reference that combines high accuracy and low drift with very low supply current and small package size. The combination of ultralow quiescent current and low dropout voltage of only 200mV max. makes them ideal for battery-powered equipment. The output voltage is set by an external resistor divider for the adjustable LTC1258CMS8-5#TR. The applications of the LTC1258CMS8-5#TR include Battery-Powered Systems, Handheld Instruments, Precision Power Supplies, A/D and D/A Converters.

Parametrics

LTC1258CMS8-5#TR absolute maximum ratings: (1)Supply Voltage: 13V; (2)Input Voltages: -0.3V to 13V; (3)Output Voltages: -0.3V to 13V; (4)Output Short Circuit Duration: Indefinite; (5)Supply Voltage: 13V; (6)Input Voltages: -0.3V to 13V; (7)Output Voltages: -0.3V to 13V; (8)Output Short Circuit Duration: Indefinite.

Features

LTC1258CMS8-5#TR features: (1)200mV Max Dropout at 10mA Output Current; (2)4mA Typical Quiescent Current; (3)0.15% Max Initial Accuracy (S8); (4)No Output Capacitor Required; (5)Output Sources 10mA, Sinks 2mA; (6)40ppm/℃ Max Drift (S8); (7)Available in Small MSOP Package; (8)Voltage Options: 2.5V, 3V, 4.1V, 5V and Adjustable.

Diagrams

LTC1258CMS8-5#TR block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
LTC1258CMS8-5#TR
LTC1258CMS8-5#TR


IC VREF SERIES 5V 8-MSOP

Data Sheet

0-2500: $1.56
LTC1258CMS8-5#TRPBF
LTC1258CMS8-5#TRPBF


IC VREF SERIES 5V 8-MSOP

Data Sheet

Negotiable
