Product Summary

The ECQV1H105JL3 is a stacked metallized film capacitor. Designed for application where high density insertion of components is required. The applications of the ECQV1H105JL3 include General purpose usage, Noise suppression for logic circuits.

Parametrics

ECQV1H105JL3 absolute maximum ratings: (1)Category temp. range: -40 to +85℃; (2)Rated voltage: 50VDC, 63VDC, 100VDC; (3)Capacitance range: 0.01 to 2.2 μF; (4)Capacitance tolerance: ±5%(J); (5)Dissipation factor: 1.0%max.(20℃ 1kHz); (6)Withstand voltage: Between terminals: Rated volt.(VDC).150% 60s; (7)Insulation resistance: C<=0.33μF : 3000MΩ min; C>0.33μF: 1000MΩ.μFmin.

Features

ECQV1H105JL3 features: (1)High volumetric efficiency; (2)Excellent electrical characteristics in non-inductive construction; (3)Wide range for automatic insertion.

Diagrams

ECQV1H105JL3 block diagram

ECQV
ECQV
