Product Summary
The LT1014ISW#TR is a precision quad operational amplifier which directly upgrades designs in the industry standard 14-pin DIP LM324/LM348/OP-11/4156 pin configuration. It is no longer necessary to compromise specifications, while saving board space and cost, as compared to single operational amplifiers. The LT1014ISW#TR’s low offset voltage of 50mV, drift of 0.3mV/℃, offset current of 0.15nA, gain of 8 million, common-mode rejection of 117dB and power supply rejection of 120dB qualify it as four truly precision operational amplifiers. The applications of the LT1014ISW#TR include Battery-Powered Precision Instrumentation, Strain Gauge Signal Conditioners, Thermocouple Amplifiers, Instrumentation Amplifiers, 4mA-20mA Current Loop Transmitters, Multiple Limit Threshold Detection, Active Filters, Multiple Gain Blocks.
Parametrics
LT1014ISW#TR absolute maximum ratings: (1)Supply Voltage: ±22V; (2)Differential Input Voltage: ±30V; (3)Input Voltage: Equal to Positive Supply Voltage; 5V Below Negative Supply Voltage; (4)Output Short-Circuit Duration: Indefinite; (5)Storage Temperature Range, All Grades: -65℃ to 150℃; (6)Lead Temperature (Soldering, 10 sec.): 300℃.
Features
LT1014ISW#TR features: (1)Single Supply Operation; (2)Input Voltage Range Extends to Ground; (3)Output Swings to Ground while Sinking Current; (4)Pin Compatible to 1458 and 324 with Precision Specs; (5)Guaranteed Offset Voltage: 150mV Max.; (6)Guaranteed Low Drift: 2mV/℃ Max.; (7)Guaranteed Offset Current: 0.8nA Max.; (8)Guaranteed High Gain, 5mA Load Current: 1.5 Million Min; 17mA Load Current: 0.8 Million Min; (9)Guaranteed Low Supply Current: 500mA Max.; (10)Low Voltage Noise, 0.1Hz to 10Hz: 0.55mVp-p; (11)Low Current Noise-Better than 0P-07, 0.07pA/√z.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LT1014ISW#TR |
|
IC OP AMP PRECISION QUAD 16SOIC |
Data Sheet |
|
|
||||||
|
LT1014ISW#TRPBF |
|
IC OPAMP PRECISION QUAD 16-SOIC |
Data Sheet |
|
|
||||||
