Product Summary
The LT1260CS#TR is a 130MHz current feedback amplifier. The LT1260CS#TR is designed for excellent linearity while driving cables and other low impedance loads. The LT1260CS#TR is a triple version especially suited to RGB video applications. These amplifiers operate on all supplies from single 5V to ±15V and draw only 5mA per amplifier when active. When shut down, the LT1260CS#TR draws zero supply current and their outputs become high impedance. The LT1260CS#TR is required to make a complete 2-input RGB MUX and cable driver. These amplifiers turn on in only 100ns and turn off in 40ns, making them ideal in spread spectrum and portable equipment applications.
Parametrics
LT1260CS#TR absolute maximum ratings: (1)Supply Voltage : ±18V; (2)Input Current : ±; (3)Output Short-Circuit Duration (Note 1): Continuous; (4)Specified Temperature Range (Note 2): 0℃ to 70℃; (5)Operating Temperature Range : －40℃ to 85℃; (6)Storage Temperature Range : －65℃ to 150℃; (7)Junction Temperature (Note 4): 150℃.
Features
LT1260CS#TR features: (1)Wide Supply Range: ±2V(4V)to ±15V(30V); (2)60mA Output Current; (3)Low Supply Current: 5mA/Amplifier; (4)Differential Gain: 0.016%; (5)Differential Phase: 0.075°; (6)Fast Turn On Time: 100ns; (7)Fast Turn Off Time: 40ns; (8)14 Pin and 16 Pin Narrow SO Packages.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LT1260CS#TR |
|
IC AMP TRPL CURR FDBK SD 16SOIC |
Data Sheet |
|
|
||||||
|
LT1260CS#TRPBF |
|
IC AMP W/SHUTDOWN TRIPLE 16-SOIC |
Data Sheet |
|
|
||||||
